Filiz Steel, located in Istanbul, Turkey, is a reliable manufacturer and supplier of Alloy Steel T9 Tubing, providing robust and high-performance solutions for essential applications in power generation, petrochemicals, and industrial processing. Crafted to meet international standards like ASTM A213 and ASME SA213, T9 tubing from Filiz Steel is recognized for its ability to endure high temperatures and pressures. With state-of-the-art production capabilities and a strong commitment to quality assurance, Filiz Steel delivers tubing solutions that satisfy the demanding needs of both local and global industrial operations.
Alloy Steel T9 Tubing primarily consists of chromium (8–10%) and molybdenum (0.90–1.10%), which contribute to its remarkable high-temperature strength, creep resistance, and oxidation resistance. The tubing boasts a minimum yield strength of around 205 MPa and a tensile strength ranging from 415 to 585 MPa. The unique composition of T9 ensures long-lasting stability under high thermal stress, while its excellent ductility and weldability make it ideal for intricate installations. These characteristics enable T9 tubing to perform reliably in environments that experience thermal cycling and sustained high temperatures.
| ASTM A213 T9 Specification & Standard | ASTM A213 T9, ASME SA213 T9 (with IBR Test Certificate) |
|---|---|
| SA 213 Gr T9 Specification | ASTM A213 & ASTM A209 BS/3059/ 90/ Part II/ 620 & 622 DIN/ 17175/ 13CrMo44 DIN/ 17175/ 10CrMo910 DIN/ 17175/ 15Mo3 |
| T9 Steel Tube Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| A213 Grade T9 Tubing Size | 6.35 mm OD to 101.6 mm OD |
| SA213 Grade T9 Pipe Thickness | 3-12mm |
| ASTM A213 Grade T9 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| Craft | Cold rolled and Cold drawn |
| SA213 Grade T9 Tube Type | Seamless / ERW / Welded / Fabricated |
| A213 Grade T9 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| T9 Steel Grade Material Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| SA213 T9 Steel Tube Length | Standard Double & In Cut length also. |
| T9 Steel Grade Tube End | Plain End, Beveled End, Treaded |
| SA213 Grade T9 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Specialized in |
|
| SA213 T9 Steel Tube Application & uses | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| SA213 T9 Composition |
0.15 max |
0.30~0.60 |
0.025 |
0.025 |
0.25-1.0 |
0.90~1.10 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| T9 | 415 min | 205 min | 30 min | 179 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a trusted manufacturer and supplier of premium Alloy Steel T5 Tubing in Istanbul, Turkey. We specialize in high-quality steel materials and offer a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a commitment to timely delivery and outstanding customer service, we use only the finest raw materials to ensure exceptional performance in demanding industrial applications. Contact us today for all your Alloy Steel T5 Tubing needs!
Alloy Steel T9 Tubing finds extensive use in superheaters, reheaters, boilers, and heat exchangers within high-efficiency thermal power plants. It’s also utilized in refineries, petrochemical facilities, and industrial steam systems where resistance to oxidation and thermal fatigue is crucial. T9 tubing is particularly appreciated for its ability to maintain structural integrity even under prolonged exposure to high-pressure steam and flue gases. Its blend of strength, corrosion resistance, and cost-effectiveness makes Alloy Steel T9 Tubing a top choice for critical piping and boiler components in energy-intensive industries.
Filiz Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Istanbul, Turkey.
