Alloy Steel T5 Tubing is a high-strength, durable tubing solution manufactured by Filiz Steel in Istanbul, Turkey. Made from premium alloy steel with elements such as chromium, molybdenum, and nickel, T5 Tubing offers excellent resistance to wear, heat, and pressure. Its precision-engineered dimensions ensure uniformity and reliability for industrial, mechanical, and structural applications. T5 Tubing is widely used in industries where durability, toughness, and corrosion resistance are essential. Its superior mechanical properties make it ideal for applications in automotive, machinery, oil & gas, and heavy engineering, ensuring long-lasting performance under demanding conditions.
Alloy Steel T5 Tubing is composed of carbon steel alloyed with chromium, molybdenum, nickel, and small amounts of manganese and silicon. This composition provides high tensile strength (typically 600–850 MPa), excellent yield strength, and superior toughness. The tubing is resistant to wear, fatigue, and deformation under heavy loads and high pressure. T5 Tubing also offers good machinability, weldability, and the ability to withstand elevated temperatures. Its combination of strength, durability, and dimensional precision ensures reliable performance in demanding mechanical, structural, and industrial applications.
| SA213 T5 Tube Standard | ASTM A213 T5, SA213 T5 (with IBR Test Certificate) |
|---|---|
| SA213 T5 Tube Specifications | ASTM A213 & ASTM A209 (T1 , Ta, T1b) BS/3059/90/PartII/620 & 622 DIN/17175/13CrMo44 DIN/17175/10CrMo910 DIN/17175/15Mo3 |
| SA213 T5 Tube Size | 6.35 mm OD to 101.6 mm OD |
| Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| SA213 T5 Tube Thickness | 3-12mm |
| SA213 T5 Tube Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| SA213 T5 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| Craft | Cold rolled and Cold drawn |
| SA213 T5 Tube Type | Seamless / ERW / Welded / Fabricated |
| SA213 T5 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| SA213 T5 Tube Length | Standard Double & In Cut length also. |
| SA213 T5 Tube End | Plain End, Beveled End, Treaded |
| Specialized in | ASME SA213 T5 Boiler Tube, SA213 T5 Heater Tube, SA213 T5 Heat Exchanger Tube |
| SA213 gr T5 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| SA213 grade T5 Tube Application | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| T5 | 0.15 | 0.30~0.60 | 0.025 | 0.025 | 1.0-2.0 | 0.45~0.65 |
| T5b | 0.15 max | 0.30~0.60 | 0.025 | 0.025 | 1.0-2.0 | 0.45~0.65 |
| T5c | 0.12 max | 0.30~0.60 | 0.025 max | 0.025 max | 0.50 max | 0.45~0.65 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| T5 | 415 min | 205 min | 30 min | 179 max |
| T5b | 415 min | 205 min | 30 min | 179 max |
| T5c | 415 min | 205 min | 30 min | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T5 Tubing in Istanbul, Turkey. We provide premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to timely delivery and exceptional customer service, we use only the finest raw materials to ensure superior performance in industrial applications with stringent requirements. Contact us today for all your Alloy Steel T5 Tubing needs!
Alloy Steel T5 Tubing is widely used in automotive, machinery, oil & gas, construction, and heavy engineering industries. It is ideal for hydraulic cylinders, structural supports, piping systems, and mechanical shafts where high strength and durability are essential. T5 Tubing is also used in pressure vessels, industrial equipment, and heavy-duty frameworks, providing reliable performance under high stress, temperature, and vibration conditions. Its toughness, wear resistance, and dimensional accuracy make it a preferred choice for engineers and manufacturers who require long-lasting, safe, and efficient tubing solutions in demanding industrial applications.
Filiz Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Istanbul, Turkey.
