Filiz Steel, based in Istanbul, Turkey, has earned a solid reputation as a reliable manufacturer and supplier of **Alloy Steel T22 Tubing**. They provide high-performance solutions tailored for industries that demand strength, durability, and the ability to withstand extreme conditions. Known for their commitment to quality and precision, Filiz Steel produces T22 tubing that adheres to international standards like ASTM A213 and ASME SA213. These tubes are specifically designed for high-temperature and high-pressure settings, making them a popular choice in power generation, refineries, and chemical processing plants. By blending modern manufacturing techniques with rigorous quality control and a customer-centric approach, Filiz Steel ensures that their tubing is dependable for critical applications.
Alloy Steel T22 Tubing primarily consists of chromium (1.9–2.6%) and molybdenum (0.87–1.13%), with iron serving as the base metal. This unique composition boosts the tubing’s strength, oxidation resistance, and thermal stability, especially in high-temperature scenarios. Typically, T22 tubing boasts a tensile strength ranging from 415 to 585 MPa, a minimum yield strength of 205 MPa, and impressive elongation for structural flexibility. These mechanical properties make T22 an excellent choice for elevated temperature environments. Additionally, it offers good weldability, formability, and resistance to thermal fatigue, making it a go-to option for long-term, high-stress industrial applications.
| ASTM A213 T22 Specification & Standard | ASTM A213 T22, ASME SA213 T22 (with IBR Test Certificate) |
|---|---|
| SA 213 Gr T22 Specification | ASTM A213 & ASTM A209 BS/3059/ 90/ Part II/ 620 & 622 DIN/ 17175/ 13CrMo44 DIN/ 17175/ 10CrMo910 DIN/ 17175/ 15Mo3 |
| T22 Steel Tube Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| A213 T22 Tubing Size | 6.35 mm OD to 101.6 mm OD |
| ASTM A213 T22 Pipe Thickness | 3-12mm |
| ASME SA213 T22 Material Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| Craft | Cold rolled and Cold drawn |
| ASTM A213 T22 Tube Type | Seamless / ERW / Welded / Fabricated |
| ASTM A213 Grade T22 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| A213 T22 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| ASME SA213 Gr T22 Tube Length | Standard Double & In Cut length also. |
| ASME SA213 T22 Tube End | Plain End, Beveled End, Treaded |
| ASTM A213 T22 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Specialized in |
|
| ASME SA213 Gr T22 Tube Application & uses | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| SA213 T22 Composition | 0.05~0.15 | 0.30~0.60 | 0.025 | 0.025 | 0.50~1.0 | 0.80~1.13 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| SA213 T22 Boiler Tube | 415 min | 205 min | 30 min | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T22 Tubing in Istanbul, Turkey. We provide premium steel materials and an extensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our comprehensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to timely delivery and exceptional customer service, we use only the finest raw materials to ensure outstanding performance in industrial applications with rigorous specifications. Contact us today for all your Alloy Steel T22 Tubing needs!
You’ll find Alloy Steel T22 Tubing commonly used in superheaters, reheaters, economizers, and heat exchangers, particularly in thermal and nuclear power plants. Its ability to withstand high temperatures and resist oxidation makes it perfect for steam boilers and piping systems that operate under high pressures. T22 is also utilized in oil and gas refineries, chemical plants, and petrochemical industries, where reliable performance under thermal and mechanical stress is crucial. The tubing’s capacity to maintain its structural integrity over long periods ensures it meets the demands of these challenging environments.
