Filiz Steel, based in Istanbul, Turkey, has built a solid reputation as a reliable manufacturer and supplier of SAE 1045 Steel Sheets and Plates. They provide top-notch carbon steel solutions to clients all around the globe. These plates are celebrated for their strength, versatility, and affordability, making them a popular choice in various industrial, engineering, and mechanical applications. Filiz Steel is committed to ensuring that its SAE 1045 products adhere to international standards, delivering impressive dimensional accuracy and consistent mechanical performance. Thanks to their state-of-the-art production facilities and rigorous quality control, the company offers 1045 sheets and plates that are perfect for heat treatment, machining, and fabrication, making them a go-to option for modern industries.
SAE 1045 Steel Sheets and Plates are medium carbon steel products primarily made of iron, containing 0.43–0.50% carbon, along with controlled amounts of manganese, phosphorus, and sulfur. This well-balanced composition gives them good strength, hardness, and wear resistance while still allowing for reasonable ductility and toughness. They boast a tensile strength of about 570–700 MPa and a yield strength of around 300 MPa, along with excellent machinability and a great response to heat treatment processes like quenching and tempering. These characteristics make SAE 1045 steel an ideal choice for applications that require a blend of strength, hardness, and formability.
| Specification | ASTM A830 AISI 1045, SAE 1045, |
| Grade | SAE J403 Grade 1045 |
| Condition | hot rolled or normalized |
| Width | 200 to 2000mm |
| Thickness | 6 to 800mm |
| Length | 2000 to 6000mm |
| Heat treated method | By flame or induction |
| MN | FE | S | C | P |
|---|---|---|---|---|
| 0.60 – 0.90% | 98.51 – 98.98% | ≤ 0.050% | 0.420 – 0.50% | ≤ 0.040% |
| MECHANICAL PROPERTIES | ||
|---|---|---|
| Metric | Imperial | |
| Tensile Strength, Ultimate | 565 MPa | 81,900 PSI |
| Tensile Strength, Yield | 310 MPa | 45,000 PSI |
| Modulus of Elasticity | 200 GPa | 29,000 KSI |
| Hardness, Brinell | 163 | 163 |
| Elongation at Break (in 50 mm) | 16.0% | 16.0% |
| Bulk Modulus (Typical for Steel) | 140 GPa | 20,300 KSI |
| Poissons Ratio | 0.290 | 0.290 |
| Shear Modulus | 80 GPa | 11,600 KSI |
| Grade | EU EN | DIN,WNr | JIS | AFNOR | BS | GOST | ISO | UNS |
| 1045 | C45E (1.1191) | Ck45 | S45C | XC45 XC48H1 | 080M46 CFS8 | 45 | C45E4 | G10450 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Length x Width | Thickness |
|---|---|
| mm | mm |
| 2000 x 1000 | 0.8 |
| 2440 x 1220 | 1.0 |
| 2500 x 1250 | 0.9 |
| 2500 x 1250 | 0.8 |
| 2000 x 1000 | 1.20 |
| 2000 x 1000 | 1.0 |
| 2000 x 1000 | 0.9 |
| 1830 x 1220 | 1.0 |
| 2500 x 1250 | 1.20 |
| Thickness | Length x Width | Mass per Sq m |
|---|---|---|
| mm | mm | Kg/m2 |
| 30.00 | 2000 x 1000 | 235.50 |
| 30.00 | 4000 x 2000 | 235.50 |
| 30.00 | 2500 x 1250 | 235.50 |
| 30.00 | 5000 x 2500 | 235.50 |
| 30.00 | 3000 x 1500 | 235.50 |
| 30.00 | 5000 x 1250 | 235.50 |
| 40.00 | 2000 x 1000 | 314.00 |
| 32.00 | 2000 x 1000 | 251.20 |
| 30.00 | 10000 x 2500 | 235.50 |
| 30.00 | 6000 x 2500 | 235.50 |
| 32.00 | 2500 x 1250 | 251.20 |
| 32.00 | 3000 x 1500 | 251.20 |
| 32.00 | 5000 x 2500 | 251.20 |
| 32.00 | 4000 x 2000 | 251.20 |
| 35.00 | 3000 x 1500 | 274.75 |
| 35.00 | 4000 x 2000 | 274.75 |
| 35.00 | 2500 x 1250 | 274.75 |
| 40.00 | 2500 x 1250 | 314.00 |
| 40.00 | 3000 x 1500 | 314.00 |
| 40.00 | 4000 x 2000 | 314.00 |
Across various industries, SAE 1045 Steel Sheets and Plates are widely used to manufacture components that demand strength and durability. They’re commonly found in the production of gears, shafts, axles, bolts, crankshafts, and other mechanical parts where wear resistance is crucial. Additionally, they play a role in machinery components, construction equipment, pressure vessels, and industrial tools. Their ability to undergo heat treatment enhances their hardness, making them a preferred option for heavy-duty applications. With good weldability under controlled conditions and excellent machinability, SAE 1045 sheets and plates are a trustworthy material for a wide range of uses.
