Filiz Steel, based in Istanbul, Turkey, has earned a solid reputation as a reliable manufacturer and supplier of HIC (Hydrogen-Induced Cracking) Resistant Steel Sheets and Plates. They provide high-performance steel tailored for critical applications in the oil, gas, and petrochemical sectors. These plates are specifically engineered to withstand hydrogen-induced cracking, sour corrosion, and various forms of material degradation in harsh environments. Filiz Steel is committed to ensuring that its HIC resistant steel products adhere to international standards, delivering precise dimensional accuracy, exceptional surface quality, and consistent mechanical properties. With state-of-the-art production facilities and rigorous quality control measures, the company offers durable steel plates that can handle extreme service conditions around the globe.
The HIC Resistant Steel Sheets and Plates are crafted from low-alloy carbon steel, featuring an optimized chemical composition with carefully controlled levels of sulfur, manganese, and other micro-alloying elements. They boast high tensile and yield strength, outstanding toughness, and remarkable resistance to hydrogen-induced cracking and sulfide stress corrosion. These plates also maintain excellent weldability, machinability, and ductility, making them perfect for fabrication into pressure vessels, piping, and structural components. Their uniform microstructure guarantees reliable performance in high-pressure, sour, and corrosive environments.
| Material | ASTM A516 |
| Grade | SA516 Gr 65, SA516 Gr 70 ,SA516 Gr 60 , Gr 60N |
| Size |
|
| Manufacturing Process | Hot-Rolled |
| Impact tested | -52° C |
Technical requirements | high strength and high toughness requirements, Detection, Z15 – Z35 thickness direction performance requirements, etc |
| Condition of Supply | Heat Treatment Simulated Post-Weld , Furnace Normalizing, As Rolled, Normalized Rolling, Vacuum Degassing or as per need |
| Base Plate | hot dipped zinc coated and A-Z coated steel sheet, Cold rolled steel sheet |
| C | ≤0.2 |
| Mn | 0.85–1.20 |
| Cu | ≤0.2 |
| Cev | ≤0.41 |
| S | ≤0.001 |
| Si | 0.15–0.40 |
| P | ≤0.010 |
| Mo | ≤0.1 |
| Ni | ≤0.4 |
| Cr | ≤0.3 |
| ASTM/ASME | DIN | European Norm | British Standard |
| A/SA516 – Grade 60 | DIN 17155 HII | EN10028 P265GH | BS1501-161-430A |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | Plates Thickness |
|---|---|
| A516 60 | ≤12.5mm |
| A516 60 | ≥100 and ≤200mm |
| A516 60 | ≥12.5 mm and ≤50mm |
| A516 60 | >200mm |
| A516 65 Dicrest only | ≥100 mm and ≤200mm |
| A516 60 | ≥50 mm and ≤100mm |
| A516 65 Dicrest only | ≤12.5mm |
| A516 65 Dicrest only | ≥12.5 mm and ≤50mm |
| A516 65 Dicrest only | ≥50 mm and ≤100 mm |
| A516 70 | >200 mm |
| A516 65 Dicrest only | >200mm |
| A516 70 | ≥100 mm and ≤200mm |
| A516 70 | ≤12.5mm |
| A516 70 | ≥50 mm and ≤100mm |
| A516 70 | ≥12.5 mm and ≤50mm |
| Lengths in mm | Plates Thickness in Inches | Widths in mm | Lbs/Sft |
|---|---|---|---|
| 240 | 7/16 Inches | 96 | 17.870 Lbs/Sft |
| 96, 120, 240 | 5/16 Inches | 60 ,48 , 84 , 72 ,96 | 12.760 Lbs/Sft |
| 96, 120, 124,133, 144, 156, 240 | 3/16 Inches | 7.660 Lbs/Sft | |
| 110, 96, 120, 240, 144 | 1/4 Inches | 10.210 Lbs/Sft | |
| 120, 96, 144, 169, 240, 260 | 3/8 Inches | 15.320 Lbs/Sft | |
| 120, 96, 144, 240 | 1/2 Inches | 20.420 Lbs/Sft | |
| 240 | 1 1/8 Inches | 96 | 45.950 Lbs/Sft |
| 96, 240, 120, 480 | 1 Inches | 48, 72, 96 | 40.840 Lbs/Sft |
| 96, 240, 120, 480 | 3/4 Inches | 48 , 72 , 84, 96 | 30.630 Lbs/Sft |
| 240 | 7/8 Inches | 96 | 35.740 Lbs/Sft |
| 240, 120, 480 | 5/8 Inches | 48 , 96 | 25.530 Lbs/Sft |
| 96, 120, 240 | 1 1/4 Inches | 48, 96 | 51.050 Lbs/Sft |
| 120, 240 | 1 1/2 Inches | 96 | 61.260 Lbs/Sft |
| 240 | 1 3/4 Inches | 71.470 Lbs/Sft | |
| 240 | 1 3/8 Inches | 56.160 Lbs/Sft | |
| 120, 240 | 2 Inches | 81.680 Lbs/Sft | |
| 240 | 2 1/2 Inches | 102.100 Lbs/Sft | |
| 1 5/8 Inches | 66.370 Lbs/Sft | ||
| 2 3/4 Inches | 112.310 Lbs/Sft | ||
| 2 1/4 Inches | 91.890 Lbs/Sft | ||
| 3 Inches | 122.520 Lbs/Sft | ||
| 120 | 3 1/2 Inches | 142.940 Lbs/Sft | |
| 120 | 6 Inches | 245.040 Lbs/Sft | |
| 120 | 3 3/4 Inches | 153.150 Lbs/Sft | |
| 144 | 3 1/4 Inches | 132.730 Lbs/Sft | |
| 144, 180 | 4 Inches | 163.360 Lbs/Sft | |
| 120 | 4 1/2 Inches | 183.780 Lbs/Sft | |
| 120 | 4 1/4 Inches | 173.570 Lbs/Sft | |
| 144 | 5 Inches | 204.200 Lbs/Sft | |
| 160 | 7 Inches | 285.880 Lbs/Sft |
These HIC Resistant Steel Sheets and Plates find extensive use in the oil and gas industry, including sour gas pipelines, refineries, and petrochemical plants. They’re also utilized in pressure vessels, storage tanks, chemical processing equipment, and offshore platforms where the risk of hydrogen-induced cracking is present. Furthermore, these plates are well-suited for high-stress structural components exposed to corrosive and sour conditions. By combining toughness, corrosion resistance, and mechanical strength, HIC resistant steel sheets and plates offer a dependable and cost-effective solution for demanding industrial applications.
