Filiz Steel, a trusted steel supplier located in Istanbul, Turkey, proudly offers high-quality **EN 9 sheets and plates** that are essential for engineering projects requiring exceptional surface hardness and impressive wear resistance. Known as 070M55, EN 9 is a medium carbon steel grade that strikes a perfect balance for components needing more strength than mild steel, while still providing better machinability and dimensional stability compared to high carbon steels. Filiz Steel provides EN 9 sheets and plates in both hot-rolled and cold-rolled forms, available in various conditions such as annealed, normalized, or heat-treated, tailored to meet specific customer needs and application requirements.
Typically, EN 9 steel contains between 0.50–0.60% Carbon, 0.70–1.00% Manganese, along with trace elements of Silicon, Sulfur, and Phosphorus. This unique composition ensures a solid balance of strength and machinability, offering a tensile strength of around 600–800 MPa in its normalized state, which can be significantly enhanced through hardening and tempering processes. EN 9 can be heat-treated to achieve a high surface hardness, making it ideal for parts that experience wear. However, due to its carbon content, welding can be tricky, so it’s important to use proper preheating and post-weld treatments.
Grade : EN9 Low Alloy Steel Plate
Thickness : from 3mm up to as thick as 150mm
Length :3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Process of Manufacturing : Hot-Rolled (HR)
| Grade | Cr | C | Ni | Si | S | Mn | P | Mo |
| EN – 9 | – | .50 – .60 | – | .05 – .35 | .040 MAX | .50 – .80 | .040 MAX | – |
| Heat Treatment | Condition Tons/SQ.inch | Tensile Stress RE MPA | RP0.2 MPA | A min on 5.65so | Impac | Hardness HB | Limited Ruling Section mm | |
| IZODFT.L.b | KCV Joules | |||||||
| Normalise | 45 | 700 | – | 12 | – | – | 201-255 | 63 |
| 39 | 600 | – | 13 | – | – | 170/223 | 250 | |
| R | 45/55 | 700/850 | 385 | 14 | – | – | 201/277 | 100 |
| S | 50/60 | 775/925 | 450 | 14 | – | – | 223/277 | 63 |
| T | 55/65 | 850/1000 | 555 | 12 | – | – | 248/302 | 19 |
| BS 970 1991 | BS 970 1955 EN | AISI/SAE | Werkstoff |
| 070M55 | EN9 | 1055 | 1.0535 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
EN 9 sheets and plates find extensive application in industries because of their high tensile strength, toughness, and resistance to wear. The plates are best suited for the production of gears, shafts, spindles, and other machine parts under high stress. They are also employed in the automotive sector for axles and connecting rods. EN 9 steel is used for heavy engineering parts like dies, tools, and rollers. It performs well in moderate wear resistance applications and is widely used in the construction machine and farm machinery.
