Jaxon Steel is a leading Turkey steel manufacturer and supplier of top-notch steel solutions in Istanbul, Turkey. We offer higher-grade DILLIMAX 690T plates and sheets that are well-known for their unmatched strength, hardness, and resistance to wear. These high-yield structural steel plates are perfect for heavy-duty applications in the construction, mining, and engineering industries. Jaxon Steel believes in precision and perfection and delivers superior-quality products that are specifically designed to serve various industrial purposes. Our proficiency and customer-centric mindset establish us as a renowned business partner for high-performance steel solutions in the Turkey and the rest of the world.
DILLIMAX 690T plates and sheets are quenched and tempered, high-strength structural steel featuring superior toughness and weldability. They consist of carbon, silicon, manganese, chromium, molybdenum, and nickel, offering high strength and endurance. The plates have a minimum yield strength of 690 MPa and superior resistance to impact, providing the best heavy-duty application. Having excellent mechanical properties with good elongation and toughness at low temperatures, DILLIMAX 690T offers better performance in critical industries such as construction, mining, and engineering, with assurance of reliability, durability, and safety in structural applications.
Grade : 70
Item : DILLIMAX 690T Structural Steel Plate
Thickness : 5 – 160mm, 6 – 60mm, 5 – 160mm
Width : 1000mm-4500mm
Length : 3000mm -18000mm
| C | Si | Мn | P | S | N | B | Сr | Сu | Мо | Nb | Ni | V |
| 0.20 max.(%) | 0.80 max.(%) | 1.70 max.(%) | 0.020-0.025 | 0.010-0.015 | 0.015 max.(%) | 0.005 max.(%) | 1.50 max.(%) | 0.50 max.(%) | 0.70 max.(%) | 0.06 max.(%) | 2.00 max.(%) | 0.12 max.(%) |
| Steel Grade | Thickness, mm | Yield strength, min MPa | Tensile strength, MPa | Elongation, min % |
| DILLIMAX 690T | ≥8 t ≤50 | 690 | 770-940 | 14 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
DILLIMAX 690T plates and sheets are quenched and tempered steel of high strength used in severe applications where high toughness and weldability are mandatory. Plates find widespread use in heavy plant equipment, constructional building, mining, and in the production of cranes since they have a better carrying capacity. The plates are employed in offshore plants, bridges, and pressure vessels where strength and durability are required to be top-notch. Its enhanced mechanical properties ensure that it is best suited for truck frames, lifting gear, and hydraulic jacks. Further, DILLIMAX 690T maximizes performance in wear-resistant operations, lowering the cost of maintenance and improving working efficiency in aggressive environments.
