Filiz Steel, a prominent manufacturer and supplier located in Istanbul, Turkey, is dedicated to providing top-notch Carbon Steel EN 10224 Pipes to industries around the globe. These pipes are crafted to comply with the rigorous European standard EN 10224, ensuring they deliver exceptional strength, durability, and reliability for even the most demanding applications. By blending cutting-edge manufacturing techniques with strict quality control, Filiz Steel guarantees precise dimensions, consistent performance, and a long lifespan. Their Carbon Steel EN 10224 Pipes have earned the trust of various sectors, including energy, construction, and industrial processing, offering cost-effective and robust solutions for high-pressure, mechanically demanding, and critical piping systems.
The composition of Carbon Steel EN 10224 Pipes primarily includes carbon steel, along with carefully controlled amounts of manganese, silicon, phosphorus, and sulfur to boost strength, toughness, and weldability. These pipes showcase impressive mechanical properties, such as high tensile and yield strength, good ductility, and strong impact resistance. Manufactured to exact tolerances, they maintain their structural integrity even under high pressure and mechanical stress. The blend of durability, workability, and wear resistance makes Carbon Steel EN 10224 Pipes ideal for industrial applications that demand reliable, long-lasting, and high-performance piping solutions.
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.17 | max 0.35 | max 0.80 | 0.04 | 0.04 | – | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10224 Pipe products in Istanbul, Turkey. Specializing in premium steel materials, we offer a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to timely delivery and exceptional customer service, Jaxon Steel ensures the supply of top-grade materials that provide outstanding performance in various industrial applications. Rely on Jaxon Steel for all your Carbon Steel EN 10224 Pipe requirements.
| 1/8″ IPS(.405″ O.D.) | 3 1/2″ IPS( 4.000″ O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″ O.D.) | 4″ IPS(4.500″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″ O.D.) | 5″ IPS( 5.563″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″ O.D.) | 6″ IPS(6.625″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″ O.D.) | 8 ” IPS(8.625″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′ O.D.) | 10″ IPS(10.750″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″ O.D.) | 12″ IPS(12.750″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″ O.D.) | 14″ IPS(14.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″ O.D.) | 16″ IPS(16.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″ O.D.) | 18″ IPS (18.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3″ IPS( 3.500″ O.D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
You’ll find Carbon Steel EN 10224 Pipes widely utilized in industries that need strong, durable, and pressure-resistant piping. They’re commonly found in oil and gas pipelines, chemical and petrochemical plants, power generation facilities, and water transport systems. In construction and infrastructure projects, these pipes act as structural supports and industrial frameworks. They’re also essential in manufacturing machinery and heavy equipment, where mechanical stress and durability are paramount. Thanks to their excellent mechanical properties, weldability, and wear resistance, Carbon Steel EN 10224 Pipes ensure a long service life, lower maintenance costs, and dependable performance.
Filiz Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Istanbul, Turkey.
