Filiz Steel, located in Istanbul, Turkey, has built a solid reputation as a manufacturer and supplier of high-quality carbon steel products tailored to meet the diverse needs of various industries. One of their standout offerings is the Carbon Steel EN 10083-2 Grade C22R Pipe, which is crafted from low to medium carbon steel and designed for mechanical applications that require exceptional cold forming and machinability. With a commitment to rigorous quality control and adherence to European standards, Filiz Steel guarantees that each C22R pipe delivers dependable performance across automotive, machinery, and general engineering sectors.
Carbon Steel EN 10083-2 Grade C22R Pipe finds extensive use in manufacturing components like bolts, studs, shafts, and other mechanical parts that require good formability and machinability. Its capacity to endure cold forming processes without sacrificing strength makes it perfect for automotive components, agricultural machinery, and light engineering applications. With its well-rounded mechanical properties and enhanced workability, the C22R pipe stands out as a cost-effective option for medium-duty mechanical components where precision and durability are essential.
| Specification | Details |
|---|---|
| Material | EN 10083-2 Grade C22R Carbon Steel |
| Product | Seamless Pipes and Tubes |
| Carbon Content | Max 0.20% |
| Manganese Content | 0.50% – 1.40% |
| Characteristics | – Low-Cost: Cost-effective option for low-carbon steel pipes – Formability: Easy to form and shape – Surface Hardness: Not as hard as high carbon steel pipes, but can be – increased through carburizing |
| Standard | Manufactured as per EN 10083-2 specification |
| Commercial Reference | Referred to as CS (carbon steel) pipes or MS (mild steel) pipes |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
| 0.17-0.24 | max 0.40 | 0.40-0.70 | 0.045 | 0.045 | max 0.10 | max 0.40 | max 0.40 | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 430 | – | – | 24 | ||
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| DIN 17204 Grade Cm22 | EN 10083-2 Grade C22R | – | ASTM A519 Grade 1021 | ASME SA 519 Grade 1021 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10083-2 Grade C22R Pipe products in Istanbul, Turkey. Specializing in premium steel materials, we offer a comprehensive range, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to reliable delivery and exceptional customer service, Jaxon Steel provides top-grade materials that ensure superior performance across various industrial applications. Trust Jaxon Steel for all your Carbon Steel EN 10083-2 Pipe needs.
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness < 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
Carbon Steel EN 10083-2 Grade C22R Pipe finds extensive use in manufacturing components like bolts, studs, shafts, and other mechanical parts that require good formability and machinability. Its capacity to endure cold forming processes without sacrificing strength makes it perfect for automotive components, agricultural machinery, and light engineering applications. With its well-rounded mechanical properties and enhanced workability, the C22R pipe stands out as a cost-effective option for medium-duty mechanical components where precision and durability are essential.
Filiz Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Istanbul, Turkey.
