Filiz Steel, a well-respected steel supplier located in Istanbul, Turkey, offers top-notch **Carbon Steel API 5L X52 PSL 1 pipes** designed specifically for oil, gas, and fluid transmission systems. These pipes are crafted in accordance with the **API 5L** specification, ensuring they meet the **Product Specification Level 1 (PSL 1)** standards, which outline the essential mechanical properties and chemical compositions needed for general pipeline service. The **X52 grade** indicates a minimum yield strength of **52,000 psi (360 MPa)**, making it a dependable option for moderate to high-pressure pipeline applications.
Constructed from **micro-alloyed carbon steel**, API 5L X52 PSL 1 pipes boast an impressive strength-to-weight ratio, along with excellent weldability and toughness. Typically, these pipes exhibit **tensile strengths ranging from 415 to 760 MPa**, making them suitable for both above-ground and underground installations. Filiz Steel offers these pipes in various diameters and wall thicknesses, available in both **seamless and welded forms**, with customizable end finishes like beveled, plain, or threaded ends. Additionally, optional coatings and non-destructive testing services can be provided to meet specific project needs.
| Grade of material | X52 / L390 (N, M, Q, R) |
| X52 Steel LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| Standard | ISO 3183 L390/ API 5L X52 |
| API 5L X52 Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2” – 26”) |
| X52 SAW | 16″ – 100″ NB |
| API 5L X52 PSL1 ERW and HFW | 1/2” NB – 24” NB |
| API 5L X52 PSL1 Pipe end | Square Cut, Chamfering, Grooved, Buttweld, Thread Cutting, Squared Ends, Deburring, Flanged Ends, Beveled End (BE), Socket, Cut Grooves, Vibrator Grinding, Coupling, Plain end (PE), Threaded Ends (Male & Female), Pub Joints, Screwed |
| Origin of X52 material | European, Chinese, Africa, Gulf, Asian, Turkey, Russian, American, Japan, Ukraine, Japanese, Indian, USA, Latin-American, Korean, |
| API 5L X52 Wall Thickness | SCH-STD, SCH160, SCH-XXS, SCH40, SCH-XS, SCH80 |
| Equivalent Standards | JIS, ANSI, EN, DIN, IS, UNI, ISO, AWWA, SS, AISI, NFA, BS, GOST, SA, KS, API, C ASTM, SAE, GB, |
| PSL Level | |
| Coating for API 5L X52 Line Pipe | Galvanized, 3PP, Varnished, 3LPE, lined pipe, Black Painting, 3PE, CRA clad, FBE, Anti-Rust Oil |
| Carbon Steel Steel Grade | Mass fraction, % based on heat and product analyses a,g | ||||||
|---|---|---|---|---|---|---|---|
| C | Mn | P | S | V | Nb | Ti | |
| max b | max b | max | max | max | max | max | |
| X52 | 0.28 | 1.4 | 0.3 | 0.3 | d | d | d |
| Pipe Grade | Tensile Properties – Pipe Body of SMLS and Welded Pipes PSL 1 | Seam of Welded Pipe | ||
|---|---|---|---|---|
| Yield Strength a | Tensile Strength a | Elongation | Tensile Strength b | |
| Rt0,5 PSI Min | Rm PSI Min | (in 2in Af % min) | Rm PSI Min | |
| X52 | 52,200 | 66,700 | c | 66,700 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| API 5L X52 Pipe types | API 5L X52 Pipe Size (mm) | Tolerances | |
|---|---|---|---|
| Hot rolled API 5L X52 Seamless Pipe | OD | <50 | ±0.50mm |
| ≥50 | ±1% | ||
| WT | <4 | ±12.5% | |
| ≥4～20 | +15%, -12.5% | ||
| >20 | ±12.5% | ||
| Cold drawn API 5L X52 Seamless Pipe | OD | 6～10 | ±0.20mm |
| 10～30 | ±0.40mm | ||
| 30～50 | ±0.45 | ||
| >50 | ±1% | ||
| WT | <1 | ±0.15mm | |
| >1～3 | + 15%, – 10% | ||
| >3 | + 12.5%, – 10% | ||
You’ll find that X52 PSL 1 pipes are commonly used in **oil and gas transmission lines**, **water distribution systems**, **natural gas pipelines**, and **petrochemical infrastructure**, where both cost-effectiveness and reliable performance are crucial. Filiz Steel guarantees that each pipe is produced under stringent quality controls, ensuring high durability, corrosion resistance, and adherence to international pipeline standards—making them a perfect choice for critical pipeline projects.
Carbon Steel API X52 5L PSL 1 Pipes are mainly used to carry oil, gas and water in pipeline systems. They are very strong and last a long time, making them perfect for moving fluids under high pressure. Carbon Steel API X52 5L PSL 1 Pipes are commonly used in both land and sea pipeline projects for oil and gas exploration, water distribution and other construction-related applications. These pipes are crucial in industries such as oil and gas, petrochemical, water treatment and power generation due to their strength and durability. Their ability to withstand high-pressure environments and harsh conditions makes them ideal for long-distance fluid transportation, ensuring reliability and performance in critical infrastructure projects.
