Filiz Steel, a reputable manufacturer and supplier based in Istanbul, Turkey, specializes in high-quality ARCELOR 400 Sheets and Plates. These products are specifically designed for heavy-duty industrial applications that demand exceptional wear resistance. Utilizing cutting-edge metallurgical technology, these plates offer remarkable durability, toughness, and a long lifespan even in abrasive environments. Filiz Steel guarantees that each ARCELOR 400 plate adheres to international quality standards, ensuring consistent performance and reliability. They are widely utilized in industries where wear and impact resistance are crucial, making them perfect for applications like mining, construction, material handling, and heavy machinery—providing a cost-effective and enduring solution for challenging operations.
ARCELOR 400 Sheets and Plates are crafted with a blend of carbon, manganese, chromium, nickel, and molybdenum, resulting in a well-balanced mix of hardness and toughness. With a nominal hardness of 400 HBW, these plates are designed to resist abrasion while still offering good impact strength. They showcase high tensile strength, excellent yield properties, and dependable fatigue resistance, ensuring they hold up under heavy loads. Despite their impressive hardness, ARCELOR 400 plates are also easy to weld and form, making them versatile for various components. Their strong mechanical properties make them ideal for industrial applications where both strength and wear resistance are vital.
Item: ARCELOR 400
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| Internal grade | Thk (mm) | %C Max | %Mn Max | %P Max | %S Max | %SI Max | %Cr Max | %Ni Max | %Mo Max | B Max | CE Max |
| SRDQH40 | Up to 20 | 0.16 | 1.60 | 0.025 | 0.010 | 0.70 | 0.50 | 0.25 | 0.25 | 40 ppm | 0.45 |
| SRDQH41 | 20.1 – 32.0 | 0.18 | 1.60 | 0.025 | 0.010 | 0.70 | 1.00 | 0.25 | 0.25 | 40 ppm | 0.48 |
| SRDQH42 | 32.1 – 50.0 | 0.22 | 1.60 | 0.025 | 0.010 | 0.70 | 1.40 | 0.50 | 0.60 | 40 ppm | 0.57 |
| SRDQH43 | 50.1 – 70.0 | 0.22 | 1.60 | 0.025 | 0.010 | 0.70 | 1.40 | 0.50 | 0.60 | 40 ppm | 0.65 |
| HARDNESS (BHN) | YS (MPa) | UTS (MPa) | %El (L0=50 mm) | Impact at -30°C (In Joules) | |
| Specified values | 370 – 430 | 900Min | 1100 | 10 | 30J Min (Longitudinal to rolling) |
| Typical indicative values for 20 mm | 390 – 410 | 1050 | 1240 | 12 | 40J |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
ARCELOR 400 Sheets and Plates find extensive use in industries that require both wear resistance and structural integrity. In the mining sector, they are commonly used for dump truck bodies, crushers, and earthmoving equipment. The construction industry employs them in concrete mixers, hoppers, chutes, and asphalt plants. In material handling, they are utilized in conveyor systems, feeders, and silos, ensuring a long service life even in abrasive conditions. Heavy machinery manufacturers also rely on ARCELOR 400 plates for bulldozers, loaders, and other equipment, making them a go-to choice for demanding applications.
